WI-TEK POE51-48V – POE Injector

Part Number: WI-POE51-48V Categories ,

The WI-TEK POE51-48V Power over Ethernet injectors provides different power and high-speed Ethernet data connection anywhere in your network infrastructure. Some of them come with industrial chipsets that can work at -40°C ~ 80°C harsh environments. Wi-Tek PoE injectors are protected by a high-quality metal shell to ensure a long service life. They have passed a series of strict tests and provide you with reliable performance.

> PoE output port
> Ethernet input port
> AC IN 100-240V
> Plug and play

HARDWARE FEATURES

WI-POE51-48V

Interface

1 10/1000Mbps PoE RJ45 Port

1 10/1000Mbps Ethernet Port

Network Media

10BASE-T: UTP category 3, 4, 5 cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

100BASE-TX: UTP category 5, 5e cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

Power Supply

AC IN 100-240V

Data In/Out

1 x 10/1000Mbps Data In

Power In/Out Port

1 x 802.3af/at PoE Out

PoE PIN

4/5(+) 7/8(-) or 1/2(+) 3/6(-)

PoE Consumption

48V 24W

LED Indicator

PWR-Power

DIP Switch

N/A

Fan Quantity

Fanless

Transmission Method

Store-And-Forward

Protection Level

6kV Lightning protection

6kV ESD Contact discharge

Advanced Functions

Mac Address Auto-Learning And Auto-Aging

Store and forward

IEEE 802.3x  flow control for

Full-duplex Mode

Backpressure for Half-duplex Mode

OTHERS

Certification

CE, FCC, RoHS

Package Dimension

205×134×47mm

DeviceDimension

113×48×30mm

Gross Weight

0.3kg

Net Weight

0.12kg

Package Contents

1 x PoE Switch

1 x Power Cord

1 x Quick Installation Guide

Operating Temperature

-10°C~55°C
